Two Platen Injection Moulding Machine

BOLE DK SERIES

The DK series two-platen hybrid injection moulding machine was designed and developed by a team of German engineering experts using European advanced technology.

The technology in this two-platen injection moulding machine has cemented it as a market leader in the industry. Starting at 520 tonnes, the range extends to the BL6800DK, which at 6800 tonnes locking force is one of the largest two-platen machines in the world.

The DK series offers a high precision, reliable injection moulding solution; especially for customers focused on the automotive, housewares and home appliance industries.

The DK series; designed in Europe, created in China.

bole DK series two platen injection moulding machine

Key Features

 New Design

The latest generation of the compact DK series of two-platen moulding machines demonstrates a smaller footprint than the previous series.
Features such as the European designed tie-bar locking system (clamp nut), with precision engineered annular mating surfaces, allow for higher loading and increased machine durability and service life.
The unique and patented tie-bar design and specification allows for accidental high overloads, with reduced risk of breaking and long tie-bar service life.

Additional Features

  • Pure two platen design with an extended opening stroke.
  • Option of high-speed platen movement by servo motor and ball screw for shorter dry cycle times.
  • Moving platen supported by highly rigid and robust sliding pedestal system can accommodate heavier moulds.
  • The synchronisation of all tie bar-locking units provides uniform loading, which helps extend the moulds useful life.
  • The design allows for less moving components and also fewer lubrication points, which saves on cost and maintenance.
  • Each injection moulding machine comes with the latest generation KEBA controllers. These widely used touch-screen units are easy to use and are proven to be reliable in the field.
For more information on our range of Two Platen Injection Moulding Machines, contact us on 0121 725 4422 or email us

Build configuration for UK
Standard DK Two Platen machines

SERIES

MAIN PARTS

BRAND

MANUFACTURED COUNTRY

1

Computer

KEBA

AUSTRIA

2

Transducer

BALLUFF

GERMANY

3

Air Switch

ABB

SWEDEN

4

Contactor

SCHNEIDER

FRANCE

5

SSR

CRYDOM

USA

6

Traveling Switch

OMRON

JAPAN

7

Proximity Switch

SONON

CHINA

8

Plasticizing Motor

POLCAIN/STF

FRANCE/CHINA

9

Seal Ring

SKF/NOK/PARKER

SWEDEN/JAPAN/USA

10

Proportinal Valve

REXROTH

GERMANY

11

Directional Valve

REXROTH

GERMANY

12

Back Pressure Valve

REXROTH

GERMANY

13

High Pressure Pipe

MANULI/GOODYEAR

ITALY/USA

14

Lubrication Pump

HERG

JAPAN

15

Pressure Gauge

TECSIS

GERMANY

16

Oil Filter

HYDAC

GERMANY

17

Gear Pump

ECKERLE

GERMANY

18

Servo Motor

SYNMOT

CHINA

19

Servo Driver

SYNMOT/INOVANCE

CHINA

**BOLE RESERVES THE RIGHT TO CHANGE ANY OF THE SUPPLIERS LISTED ABOVE WITHOUT NOTICE.
